Car Camera Lens Smart Auxiliary Drive Lens for Expand field of vision
· Name: Intelligent auxiliary drive track offset and ranging lens
· Brand: GTD
· Material: Glass
· Uses: digital products, such as sports DV, aerial photo, panorama camera, recorder for law enforcement, AR/VR etc; and industrial products, such as smart iris recognition for machine, scanner, laser instruments and instruments widely used in optical field.
Product Details
| SPECIFICATION: | HK-9059 |
| Sensor size | φ4(1/4.5") |
| WAVELENGTH | λ 400-700nm(COLOR) |
| FOCAL LENGTH (EFL) | f 1.27 mm |
| F/NO (INFINITE) | F/NO 2.7 |
| BACK FOCAL LENGTH | BFL 2.54 mm |
| FLANGE BACK LENGTH | FB 2.34 mm |
| FIELD OF VIEW (DIAGONAL) | D 133°H 116°V 96.4° |
| RELATIVE-ILLUMINATION | >35% |
| THREAD SIZE | φ11, |
| ELEMENT | 4G+IR |
EXAMPLE:
AS:
Product features
1.Expand field of vision: The RVC system can provide a wider field of vision than traditional rearview mirrors, effectively reducing blind spots and improving safety. (For example, the CMS system of some commercial vehicles provides a 180-degree field of view angle, which can better cover the blind area behind the vehicle compared to the 140-degree field of view angle of traditional rearview mirrors.)
2.Waterproof and dustproof design: RVC lenses usually adopt waterproof design to adapt to various harsh weather conditions such as rainy days, foggy days or at night.
3.Temperature characteristics: RVC lenses need to have good temperature characteristics to ensure high-definition effects.
4.Optical distortion correction: RVC lenses usually have optical distortion correction function to provide a more realistic real scene.
5.Anti-interference ability: RVC lenses should have good anti-light interference ability to ensure high-quality images can be obtained under different lighting conditions.
6.Installation location: RVC lenses are generally installed at the rear of the vehicle to capture images behind the vehicle.
7.Guidelines: Adding guidelines in the reversing image can intuitively help drivers judge the distance between the rear of the vehicle and obstacles behind, so that measures can be taken in advance before a collision to avoid accidents.
Why Choose Us
1. Strength Factory: Top10 optical lenses manufacturers in China. More than 18 years manufacturing experience, multi-production lines to guarantee quick delivery.
2. Professional Team: We own more than 95 engineers in the research and development team. By 2024, 178 patents had been granted. Equipped with automated production line, master all the core manufacturing industry chain.
3. High Quality: With the advanced metrology instruments and impeccable quality assurance system, AICO was ISO9001, ISO/TS 16949 and ISO 14001 certified with SGS.
4. Professional & considerate after service: You can inquiry us any questions about the lenses.We can give you professional solutions.Most of the salespeople have more than 5 years of experience in the optical lens industry, the team is strong, the division of labor is clear, can respond quickly, save your time and energy.
PRODUCTION PROCESS
1 check and clean materials
2 assemble bottom lens/spacer
3 assemble middle lens/spacer
4 waterproof rubber ring
5 assemble top lens
6 lock lid
7 profile check
8 surface check
9 gelling UV glue
10 solidify UV glue
11 waterproof test(air tightness test)
12 vibration test
13 clean surface dust cap
14 stick IR
15 spot check finish product/warehouse if qualified
